Rotax 503 UL DCDI User Manual

d04094
page 10 - 4
Jan. 01/2007
Effectivity: 503 DCDI
OM Edition 1 / Rev. 0
BRP-Rotax
02786
02785
02784
fig. 15
fig. 16
fig. 17
b) 503 UL DCDI
MOTORLEISTUNG / ENGINE PERFORMANCE
5
10
15
20
25
30
35
40
3000 3500 4000 4500 5000 5500 6000 6500 7000
engine speed [RPM]
performance [KW]
503 UL DCDI 2V
503 UL DCDI 1V
10
20
30
40
50
performance [hp]
max. 6800
MOT ORDREHMOMENT / ENGINE T ORQUE
15
20
25
30
35
40
45
50
55
60
3000 3500 4000 4500 5000 5500 6000 6500 7000
engine speed [RPM]
torque [Nm]
503 UL DCDI 2V
503 UL DCDI 1V
torque [ft.lbf.
]
20
30
40
max. 6800
TREIBSTOFFVERBRAUCH / FUEL CONSUMPTION
500
600
700
800
900
1000
1100
1200
3000 3500 4000 4500 5000 5500 6000 6500 7000
engine speed [RPM]
fuel consumption [g/kWh]
503 UL DCDI 2V
503 UL DCDI 1V
1,0
1,2
1,4
1,6
1,8
fuel consumption [lb/hph]
max. 6800
