Rotax 914 series - Performance Data (Variable Pitch Propeller)

Effectivity: 914 Series BRP-Powertrain page 5-4
OM Edition 2 / Rev. 0 April 01/2010
d04477.fm
Performance data Performance data for variable pitch propeller
Engine speed over 5500 rpm is restricted to 5 minutes.
Run the engine in accordance with the following table.
Power
setting
Engine
speed
(rpm)
Perfor-
mance
(kW)/(HP)
Torque (Nm)
(ft.lb.)
Manifold
press.
(in.HG)
Throttle
position
(%)
Take-off
power
5800 84.5 115 139
102
ft.lb
39 115,0
max. con-
tinuous
power
5500 73.5 100 128 93 ft.lb 35 100,0
75 % 5000 55.1 74 105 77 ft.lb 31 approx. 67
65 % 4800 47.8 64 95 70 ft.lb 29 approx. 64
55 % 4300 40.4 54 90 66 ft.lb 28 approx. 59
