3.6 Hooks for draining bags
The two (2) hooks for the draining bags are located under and on each side of the
lower back section of the platform.
The eight (8) openings for the restraining straps located on each side of the lower
back and the thighs sections of the platform can also be used for draining bags.
NOTE: The four (4) openings located on each side of the thighs section can be
moved when the angle is modified. Ensure that the bag does not hook the side rails when
moving.
3.7 Openings for restraining straps
The ten (10) openings for restraining straps are located on each side of the
platform (see p.8). It is the medical staff’s responsibility to use properly the restraining
straps and to choose the appropriate openings. Make sure that the straps do not tighten
more when moving the platform.
3.8 I.V. pole holders
Six (6) receptacles are at the head end of the bed, they offer tree different
dimensions.
Hooks for draining
bags (2)
