6
1.7 Measurement specifications
1 Overall length (A): 2365 mm (93 1/8 in)
NOTE: The overall length is expandable up to 2568mm (101 1/8 in) (with head
and foot panel). The platform is expandable from 2032mm up to 2235mm (80 in
to 88 in)
2 Overall height (B): 2417 mm (95 1/4 in)
(With trapeze bar and the bed at its highest position)
3 Overall width: - Half side rails (C) : 1016 mm (40 in)
NOTE: The overall width is expandable up to 1511 mm (59 1/2 in) (with side
rails)
The platform is expandable from 889mm up to 1372mm (35 in to 54 in)
4 Height of bed without mattress: - Lowest position (D): 211 mm (8 5/16 in)
- Highest position (E): 813 mm (32 in)
5 Distance between the head and the tip of the trapeze bar (F): 871 mm (34 5/16 in)
C
C
C
E
A
B
D
F
