Rotec Versatech 1100 - Technical Specifications; Safe Working Load; Bed Weight; Included Accessories

4
!
Legend
: Used when special attention to the indications is needed in order to avoid any
injuries and/or equipment failure.
1. TECHNICAL SPECIFICATIONS
1.1 Safe working load
The maximum safe working load (SWL) for this bed is 500 kg (1100 lbs).
1.2 Bed weight
The bed weighs ~ 199 kg (~ 438 lbs). The weight of the bed may vary depending
on the options and accessories installed on it.
1.3 Accessories
- Remote control
- Mattress retainers
- Emergency battery for temporary autonomy
- Nurse control at the foot end of the bed
- CPR (electrical) and light underneath the bed
- Casters with synchronized brake system
- Composite half side rails
- Composite covering for the platform
Headboards and footboards available:
- wooden headboard
- wooden footboard
- composite headboard
- composite footboard
Optional accessories available:
- Bar with trapeze
- Patient control integrated to the side rails
- Nurse call in lieu of the light feature
- 127 mm (5 in) thick mattress (available separable in sections)
- Bed trolley
- Scale system with display at the foot end of the bed
1.4 Electrical specifications
Nominal voltage: 120 VCA
Cycles: 60 Hz
Maximum power: 2,7 A
Operation cycle: 10%, maximum (2 min / 18 min)
Protection: This product is certified IPX4.
The electric components are certified IP54.
