25
3.9.2.2 To extend the platform:
*It is recommended to raise the foot section in order to easily extend the length of the
platform
1- Pull on the cable 1 located beneath the platform foot section, on the frame;
2- With the other hand, pull on the foot frame extension;
3- Release the cable and the extension will automatically lock to the following
mattress length: 84 in & 88 in.
4- Pull on cable 2 located directly beneath the platform foot section;
5- With the other hand, pull on the foot platform extension;
6- Release the cable and the extension will lock to the same dimension (84 in & 88 in).
CABLE 1
CABLE 2
