3 TECHNICAL SPECIFICATIONS
Input Power Voltage
One Phase 115 ± 10 VAC (USA and Canada)
230 ± 20 VAC (Outside USA and Canada)
0.5
Amp, 50-60Hz
Relay Loads
5.0 Amps, 250 Volts, Fused
Analog Inputs
0 - 11 Volts, 10 Milliamps Maximum
Analog Output
0 - 10 Volts:
Current Limited with 100-Ohm Resistor
Digital Inputs
5 ma @ 5 Volts, Dry Contact
Operating Temperature Range
0° to +50° C (32° to 125° F)
Enclosure
Water and Dust Tight
Fuses
Main fuse: 0.315 Amps, 250 Volts
Others: 5 Amps, 250 Volts
