User manual
Room air conditioner - TETA X
EN
PART 1. INDOOR & OUTDOOR UNITS
1. INDOOR UNIT
2. OUTDOOR UNIT
8
1
1. Mounting plate
2. Air lter
3. Air inlet
4. Front panel
5. Emergency button
6. Air outlet
7. Air deector and ap
8. Refrigerant connecting pipe
2
3
4
5
6 7
9. Air outlet
10. Air inlet
11. Wiring cover
12. Drainage pipe
13. Connection wiring
14. Valve protective cover
15. Gas valve (Low pressure valve)
16. Liquid valve (High pressure valve)
9
10
11
12
13
14
15
16
NOTE
All the pictures in the manual are for
explanation purposes only. Your unit
may be slightly dierent. The actual
shape shall prevail. The operations
and functions are the same.
