Rotenso WINDMI Series - Page 44

44
User manual
Wired control - ORIS
EN
No. Item Description
d. Then press “conrm” button to set MaxWSP, press “up” or “down” to set
the value of MaxWSP;
e. Press the “conrm” button to go to step 6;
6. Press the “up” or “down” button to set the heating climate oset from
-5~5°C, default as 0°C; then press “conrm” button to conrm and exit or
“setting” button to go to next item.
4
Capacity test
setting
Reserved
5
3-way valve type
select
0 - Normal open
1 - Normal closed
6 DI1
0 - Disable
1 - Power limitation (night mode)
2 - Load-shed
3 - DHW request
4 - Anti-legionella request
5 - DHW priority
7 DI2
8 DI3
9 DI4
10 DO1
0 - Disable
1 - Unit in alarm
2 - Unit in standby
3 - Unit running
4 - Unit in cooling
5 - Unit in heating
6 - Unit in DHW
7 - Unit in defrost
8 - Unit controlled by Modbus
11 DO2
12 DO3
13
Eco mode cooling
setpoint oset
If choose air setpoint, it is air setpoint oset, otherwise is water setpoint oset
0~10°C, default as 2°C
14
Away mode cooling
setpoint oset
If choose air setpoint, it is air setpoint oset, otherwise is water setpoint oset
0~10°C, default as 4°C
15
Eco mode heating
setpoint oset
If choose air setpoint, it is air setpoint oset, otherwise is water setpoint oset
-20~0°C, default as -2°C
16
Away mode
heating setpoint
oset
If choose air setpoint, it is air setpoint oset, otherwise is water setpoint oset
-20~0°C, default as -4°C
17
Eco mode DHW
setpoint oset
-10~0°C, default as -5°C
18
Minimum OAT for
heating
-26~10°C, default as -26°C
19
Booster OAT
Threshold
-10~0°C, default as -5°C
20
Heat pump
warmup time
0~120min, default 60min
