3.2. TECHNICAL PARAMETER CONFIGURATION
Press and hold the “setting” button to go into the technical parameter conguration interface, and press
“setting” button to turn down the setting item from 0-25. You can use “up” or “down” button to change the
value of each item.
Details of the user parameter conguration table as below:
No. Item Description
0
Control setpoint
type
0 - Water setpoint control
1 - Air setpoint control
1
Controller
selection
0 - Wired controller
1 - Dry contact
2 Back up function
0 - Main water loop EHs + DHW EHs + boiler
1 - Main water loop EHs + DHW EHs
2 - DHW EHs + boiler
3 - Main water loop EHs + boiler
4 - DHW EHs only
5 - Boiler only
6 - Main water loop EHs only
7 - Non back up
3 Back up function
0 - Non climate curve
1 - Climate curve
After set the 1 with climate curve, please follow the below steps:
1. After choose 1, enter heating climate setting, press “up” or “down” button to
choose the climate curve 1-13, if choose 1-12, press “conrm” button, then
go to step 3; if choose 13, press “conrm” button, then go to step 2;
2. Customized heating curve value input:
a. Press “up” or “down” to set the value of MinOAT;
b. Then press “conrm” button to set MaxOAT, press “up” or “down” to set
the value of MaxOAT;
c. Then press “conrm” button to set MinWSP, press “up” or “down” to set
the value of MinWSP;
d. Then press “conrm” button to set MaxWSP, press “up” or “down” to set
the value of MaxWSP;
e. Press the “conrm” button to step 3;
3. Press “up” or “down” button to set the heating climate oset from -5~5°C,
default as 0°C; then press “conrm” button to go to step 4;
4. Enter cooling climate setting, press “up” or “down” button to choose the
climate curve 1-3, if choose 1-2, press “conrm” button, then go to step 6; if
choose 3, press “conrm” button to go to step 5;
5. Customized heating curve value input:
a. Press “up” or “down” to set the value of MinOAT;
b. Then press “conrm” button to set MaxOAT, press “up” or “down” to set
the value of MaxOAT;
c. Then press “conrm” button to set MinWSP, press “up” or “down” to set
the value of MinWSP;
