11 x Technical data
66
FA ROTEX A1 BO - 10/2007
Tab. 11-3 Classification of burner components in the A1 BO
Integrated connection group
Tab. 11-4 Technical data of the integrated connection group
Boiler type A1 B0 15bio A1 B0 20i A1 BO 27i A1 BO 35i
Burner type ROTEX BL 15 ROTEX BL 20 ROTEX BL 27 ROTEX BL 35
Automatic firing unit DKO 974 Mod. 5 (Satronic)
Flame monitor Satronic IRD 1010 red axial or BST Solutions KLC 2002 axial
Ignition transformer Beru Type MKZ 100 No. 0 096 600 017: 2x 7.5 kV, 20 kHz
or Danfoss Type EBI No. 052 F0077: 2x 7.5 kV, 20 kHz
Solenoid valve Danfoss Type 071 N 0051
Oil pump, pumping capacity Danfoss Type BFP 21 L3 LE, No. 071 N2110
Oil preheating Danfoss Type FPHB-LE/PTC 70 No. 030 N4101
or Danfoss Type FPHB-LE/PTC 50 No. 030 N4257
Motor ACC EB 95C 28/2, 90 W ACC EB 95C 52/2, 180 W
Boiler type A1 BO 15bio A1 BO 20i A1 BO 27i/A1 BO 35i
Heating circulation pump Grundfos ALPHA+15-40 CES Grundfos UPS 15-60 N1 CES 87 Grundfos ALPHA+15-60 N1 CES
Voltage 230 V, 50 Hz
Maximum power consumption 45 W 90 W 80 W
Protection type IP 42 IP 44 IP 42
Permitted overpressure 3 bar
Maximum pumping height 3.8 m 6.0 m 6.2 m
3-way diverter valve
Voltage 230 V, 50 Hz
Maximum power consumption 4.3 W
Protection type IP 40
Turnaround time 6 s
