• Environmental Condition
➢ Standard temperature range
o -20° to +85°C / -4° to +185°F
➢ Low temperature range
o -40° to +85°C / -40° to +185°F
o -55° to +135°C / -67° to +185°F available on request
➢ Influence of temperature on valve position
o 0.35% /10°K
➢ Influence on valve position
o <1% under 10g 5-85 Hz. 2.5 85-150 Hz
o 1.5g, 150-280 Hz, 0.5g 280-1500 Hz
• Construction/Enclosure
➢ Material
o 1=Epoxy coated anodised aluminium housing & Makrolon ® (Polycarbonate) cover
o 2 =Epoxy coated anodised aluminium housing & cover with Makrolon ® see through
window
o 3 =Explosion proof aluminium housing & cover with toughened glass see through
window
o 4 =Explosion proof stainless steel housing & cover with toughened glass see
through window
o 5 =Intrinsically safe, epoxy coated anodised aluminium housing & Makrolon ®
(Polycarbonate) cover
o 6 =Intrinsically safe, epoxy coated anodised aluminium housing & cover with
Makrolon ® (Polycarbonate) cover
o 7 =Intrinsically safe, stainless steel housing & cover with toughened glass see
See through window
➢ Protection class
o Ip66
➢ Pneumatic pressure ports
o G1/4”
o ¼” NPT
➢ Exhaust port
o G1/4”
o ¼” NPT
