Variant 2 – rebate clearance 4 / 12 mm
Mat. no. 820187 Mat. no. 820194
Installation situation
1
4
2
3
[1] Frame component
[2] Leaf component
[3]
Retaining bracket (  from page 44)
[4]
Cover plate (  from page 45)
