1 General information
1.1 Version history
Version Date Changes
v0 17.04.2019 Publication
v1 12.11.2019
Overview drawing of installation situation
from page 20
v2 26.05.2020
Cable junction 820255 with built-in cover plate
from page 17
Routing dimensions corrected
from page 26
1.2 Instructions
This manual contains important information, instructions, application
diagrams (max. sash sizes and weights) and assembly instructions for the
installation, maintenance and operation of hardware.
The information and instructions contained in this document refer to
products belonging to the Roto hardware system named on the front page.
All steps must be completed in sequence.
The following documents apply in addition to these instructions:
■
Roto Safe catalogue: CTL_86
■
Roto Safe Eneo connection diagrams: IMO_310
■
Roto Safe Eneo C / CC / CF installation instructions: IMO_438
■
Brief instructions
Roto Safe Eneo A / AF and Eneo C / CC / CF: SUG_11
Power supply unit specifications: SUG_3
■
Instructions and information relating to the individual hardware
■
The applicable regulations, directives and national laws
Storing the instructions
These instructions are an important part of the product. The instructions
must be stored so that they are always to hand.
Explanation of the markings
The manual uses the following markings for emphasis (e.g. in figures or
instructions):
Marking Meaning
Sash
Frame
Drill holes, routing or screw positions
Unaffected components
Indirectly affected components
Components that have just been described
Arrows or movements
Item number
[1] Legend
[A] Steps
General information
6 · 05 / 2020 · IMO_502_EN_v2
Roto Safe - Cable junctions Subject to change.
