Roto Safe - Drilling and routing dimensions

Sash side with casing (U-shape)
1
25
45
210
230
20
4.3 Drilling and routing dimensions
INFO
The drill holes must be free from burr and swarf.
INFO
Only tighten screws by hand.
Recommendation: predrill screw holes.
Frame component without power supply unit + leaf component without casing
238
12.5
35
10
5.5
1
[1] Routing depth: 30 mm
Installation
Drilling and routing dimensions
26 · 05 / 2020 · IMO_502_EN_v2
