Frame side with power supply unit
43
400
24
41.6
3
180
376
19.4
100.2
10
Ø5
206.2
Sash components
Sash side without casing (lengthways installation)
3
10
62
110 126
Ø 4.9
Ø
3.2
16
11.8
Installation
Dimensions
Subject to change. Roto Safe - Cable junctions
