Roto Safe - Overview of variants

3.4 Overview of variants
Variant 1 – rebate clearance 12 / 16 mm
Mat. no. 820187 Mat. no. 820255
Installation situation
1
3
2
[1] Frame component
[2] Leaf component
[3]
Cover plate (  from page 45)
