Rotronic HygroPalm Series User Manual

Page 11 of 33
in-hypalm-v40 / 20051205
HygroPalm Function Menu
To access the HygroPalm function menu, press the MENU key. The first menu item appears on the
message line of the LC display. Use the UP or the DOWN key to navigate the menu. When the desired
menu item appears on the message line of the LC display, press the ENTER key to select. Some menu
items have sub-items. These can be selected with the UP, DOWN and ENTER keys. To exit the menu
and return to the normal display mode, press the MENU key. The instrument also returns automatically to
the normal display mode when no key is being pressed for some time (main menu: 10 sec., submenu: 30
sec.).
CALCULATE
Definition
This function is used to select or view the humidity parameter that is calculated by the instrument. The
calculated parameter is selected individually for each probe connected to the instrument
1)
. Prior to
entering this function, select on the display the probe to programmed.
1) does not apply to third-party analog probes.
The unit system (Metric or English) is factory programmed according to what was specified when the
instrument was ordered. The unit system can be changed by the user from the keypad (see MENU,
SETTINGS) or with the optional HW3 or HW4 software.
Selections
Parameter M E HygroPalm 1 HygroPalm 2 HygroPalm 3
Dew Point / Frost Point
1)
°C °F
x x x
Wet Bulb Temperature
2)
°C °F
x x x
Enthalpy
2)
J/g BTU/lb N/A
x x
Vapor Concentration g/m
3
gr/cuft N/A
x x
Specific Humidity
2)
g/kg gr/lb N/A
x x
Mixing Ratio
2)
g/kg gr/lb N/A
x x
Vapor Concentration
at Saturation
g/m
3
gr/cuft N/A
x x
Partial Pressure
of Water Vapor
hPa PSI
In Hg
N/A
x x
Saturation Pressure
of Water Vapor
hPa PSI
In Hg
N/A
x x
1) The standard factory setting is frost point for values below freezing. This setting can be changed to dew point with
the optional HW3 or HW4 software (except HygroPalm 1)
2) Calculation of this parameter requires barometric pressure as an input. The fixed value used for barometric
pressure can be changed either directly from the keypad (except HygroPalm 1) - see MENU, SETTINGS - or with the
optional HW3 or HW4 software (all models). The HygroPalm 3 can also be configured to accept the input from an
analog pressure probe (variable pressure value).

Rotronic HygroPalm Series Specifications

General

Protection	IP40
Humidity Measurement Range	0 to 100 %RH
Display	LCD
Power Supply	Battery
Interface	USB
Weight	250 g
Calculated Parameters	Dew point, wet bulb temperature
