Page 12 of 33
in-hypalm-v40 / 20051205
DISPLAY
Definition
This function is used to select which parameters are displayed by the instrument. The display mode is
specified globally for all probes connected to the instrument.
Selections
- Measurement
Relative humidity and temperature or the parameter measured by any third party probe
connected to the instrument.
- Calculated + Temperature
Calculated parameter (as selected under CALCULATE) and temperature. This selection is not
available with third-party probes.
- Calculated + Humidity
Calculated parameter (as selected under CALCULATE) and relative humidity. This selection is
not available with third-party probes.
- User Calc (HygroPalm 2 and HygroPalm 3 only)
User defined calculation such as the difference between temperature and dew point of any probe.
The display shows only the calculated value. See the separate HW3 or HW4 manual for
instructions on how to program the HygroPalm 2 or 3 to compute a user specified parameter.
ADJUST M.PT (full calibration against a reference environment)
Note: this function is not available with the HygroPalm 1
Definition
The Adjust M.PT function permits the full calibration of any ROTRONIC HygroClip digital probe against a
known reference environment. This function is designed to permit calibration at 2 temperature values and
at up to 4 relative humidity values.
Selections
The Adjust M.PT function offers the following choices (use the UP and DOWN keys):
RHS: Humidity calibration using the ROTRONIC Humidity Standards
1)
Humidity: Humidity calibration using any suitable reference environment
Temperature: Temperature calibration using any suitable reference environment
1) For humidity calibration, ROTRONIC offers convenient, certified humidity standards to generate known
humidity values (for more details, see Appendix 3 - Humidity Calibration).
