Page 9 of 33
in-hypalm-v40 / 20051205
Keypad
Operation
ON/OFF: Turns the instrument on or off and also
controls the HOLD function
MENU: Press this key to activate the Function Menu.
The different menu items appear on the LCD
message line. Press this key again to exit
the menu
UP / DOWN: Press one of these keys to change the probe
input that is being displayed. When the
menu is active, use these keys to navigate
the menu, make a selection or to change a
value
ENTER: When the menu is active, press this key to
confirm a selection.
Probe input 2:
- connecting cable
to transmitter
(use cable # AC1620)
- analog probe
- second HygroClip probe
with adapter cable
Probe input 1:
HygroClip digital probe
RS232 port (to PC)
use cable # AC1622
HygroPalm 2 and HygroPalm 3 only
