Roundup VCT-250 - REPLACEMENT PARTS (continued); Hardware List

22
P/N 1010776 Rev. H 03/04
McDonald’s
RAPID TOASTER VCT-250
23
P/N 1010776 Rev. H 03/04
McDonald’s
1 0011266 Conveyor Belt Assy. (Crown) A&B 1
A 0800204 1/2” Pitch Link, Small 2
B 0800121 3/4” Pitch Link, Large 38
2 0011264 Conveyor Belt Assy. (Heel) A&B 1
A 0800204 1/2” Pitch Link, Small 4
B 0800121 3/4” Pitch Link, Large 37
3 2150117 Idler Shaft 2
4 7000251 Conveyor Cover Assy., Frnt. (Heel/Club) 1
5 7000252 Conveyor Cover Assy., Rear (Crown) 1
6 0011242 Tensioner Assy., Front 2
7 0011262 Tensioner Assy., Rear 2
8 0800332 Rod, Conveyor Cover 4
9 7000207 Sprocket w/Setscrew 8
10 7000199 Spacer Kit (Pack of 2) 1
11 7000230 Control Cover (Incl. #48) 1
13 2150118 Drive Shaft 2
14 0700437 Power Cord/Plug, IEC 309 1
Mfg. No. 9210609
0700482 Power Cord/Plug, Pin & Sleeve (Std.) 1
Mfg. No. 9210600 & 9210618
0700495 Power Cord/Plug, Twist & Lock Angle 1
Mfg. No. 9210602 & 9210620
0700577 Power Cord/Plug, Twist & Lock Straight 1
Mfg. No. 9210604, 9210612, & 9210622
15 7000310 Control Board 1
16 7000296 Ball Bearing (Pack of 2) 1
20 7000167 Bearing & Retainer Kit 6*
*(See note below)
21 2150181 Sprocket, Drive w/Setscrew 2
22 2150215 Drive Chain For Mfg# 9210600, 602, 1
604, 620, and 622
2150187** Drive Chain For Mfg# 9210609 & 612 1
23 0011299 Idler Sprocket & Bearing 1
24 0501232 Bracket, Idler Sprocket 1
25 0503589 Bracket, Motor Mounting 1
26 7000364 Drive Motor Kit (Incl. #78) 3 RPM/17 Secs 1
For Mfg# 9210600, 602, 604, 618,
620, and 622
7000240** Drive Motor Kit (Incl. #78) 9 RPM/10 Secs 1
For Mfg# 9210609, & 612
27 2150112 Sprocket, Motor w/Setscrew 1
28 Tooth, 17 Seconds 60Hz.
Mfg# 9210600, 602, 604, 618, 620, & 622
2150129** Sprocket, Motor w/Setscrew 1
16 Tooth, 10 Seconds 60Hz.
Mfg# 9210612
2150110 Sprocket, Motor w/Setscrew 1
20 Tooth, 10 Seconds 50Hz.
Mfg# 9210609
28 4010137 Rocker Switch, On/Off (250 VAC) 1
29 406K006 Terminal Block 1
30 405K125 Relay, Solid State 2
31 4010187 Transformer 1
32 7000183 Conveyor Belt Wrap (Pack of 2) 1
33 7000186 Roller Tensioner Assy. (Pack of 2) 1
34 0021164 Bun Feeder 1
35 0503496 Tensioner Bracket, RH 2
36 0503497 Tensioner Bracket, LH 2
37 1001006 Label, Control 1
38 10P1118 Label, Dial (Pack of 10) YELLOW Color 1
for Mfg# 9210600, 602, 604, 618,
620, and 622
10P1026** Label, Dial (Pack of 10) GRAY Color 1
for Mfg# 9210609 & 612
39 2100253 Knob, Control 2
40 7000232 Cover, End 1
41 4050214 Thermocouple Assy. (Platen) 1
42 0021175 Weldment, End Housing 1
43 7000110 Release Sheet (Pack of 3) -
7000111 Release Sheet (Pack of 10) -
44 0021174 Control Housing 1
45 7000121 Slide Rail Kit (Includes 2 slide rails 2
for 2 tensioners)
46 0021183 Conveyor Cam 2
47 7000176 Thermocouple Retainer Kit 1
48 2100212 Lifting Handle 2
49 4030332 High Limit Thermostat 1
50 0400315 Strain Relief 1
51 0400138 Locknut, 1/2” 1
52 0503405 Base, Outer 1
53 4030326 Heater, Bun Landing 1
54 0503407 Base, Inner 1
55 0503590 Bracket, Motor 1
56 0700570 Wire Set (not shown) 1
57 0200211 Gasket, Base 1
58 0503425 Bun Chute 1
59 4030349 Auxiliary Heater, Air (208 VOLT) 2
4030348 Auxiliary Heater, Air (230 VOLT) 2
60 7000165 Auxiliary Thermocouple Kit 1
61 7000303 Platen (208 VOLT) 1
7000304 Platen (230 VOLT) 1
62 0021182 Weldment, Fan Duct 1
63 4000138 Axial Fan 1
65 4010107 Interlock Switch 2
66 0503359 Bracket, Relay 1
67 0503150 Heater Clip 2
68 0021177 Heat Shield, Front 1
69 0021178 Heat Shield, Rear 1
70 303P127 Hinge Pin, Belt Wrap (Pk. of 10) 1
71 1001023 Label, Caution Hot (Mfg# 9210609 & 612) 1
72 0503368 Fascia, Bun Stop (Mfg# 9210609 & 612) 1
73 0900225 Bun Stop (Mfg# 9210609 & 612) 1
74 7000226 Inner Conveyor Cover 2
(w/hinge bracket)
75 7000248 Teflon Damper Kit
(Includes 4 - #90 & 2 Dampers) 1
76 0503367 Clamp, Damper 2
77 0503321 Bracket, Auxiliary Thermocouple 1
78 4000170 Fan Blade, 1
79 2100252 Teflon Slip Strip 2
80 0503448 Damper Support Bracket 2
81 0503455 Tension Spring, Inner 4
82 2100259 Slide Bar 4
83 0502199 Spacer 4
84 0500464 Retainer, Bearing 1
85 0900228 Bun Gauge 1
87 7000203 Thermocouple Retainer/Chain Guard Kit 1
88 0503495 Retainer, Tensioner Bracket, RH 2
89 0503507 Retainer, Tensioner Bracket, LH 2
90 060P132 Damper Support Spring (Pack of 10) 1
91 0021311 Hinge Bracket Weldment 4
92 0503860 Hinge Bracket 1
(for Mfg# 9210612 - Japan Only)
93 2110168 Hinge, Bun Stop (Mfg# 9210600, 602, 1
604, 618, 620, and 622)
*Note 7000167 Single Bushing & Retainer Kit 6
7000224 6 Bushing & Retainer Kits 1
** See “Toasting Time Change” in the Specifications section.
Item Part No. Description Qty.
Item Part No. Description Qty.
