OPTIONAL ACCESSORIES
Bun Buffer Landing Zone (Accessory) The
optional Bun Buffer Landing Zone consists of the follow-
ing parts:
1 BBLZ Main Assembly (P/N 0011741)
2 Front Panel Assembly (P/N 0021328)
3. Thumb Screw (P/N 3080191)
2
1
There is also a kit for the Bun Buffer Landing Zone
available for purchase. It consists of the following parts:
1. Bun Buffer Landing Zone Kit (P/N 7000378)
a, BBLZ Main Assembly (P/N 0011741)
b. Front Panel Assembly (P/N 0021328)
c . Bun Chute (P/N 0503425)
d. Instruction Sheet (P/N 1010842)
Figure 20. Optional Bun Buffer Landing Zone Kit
3
