Now tucking up and routing all the front + rear camera cables
neatly. See the rear camera’s wiring diagram on the next page.
15
Check the complete wiring at a glance diagram below to
ensure everything is connected properly.
Car Cigarette Lighter
6M Cable
12FT USB
Cable
ROVE R3 Dash Cam
ROVE R3 Rear Cam
Make sure that you align and properly connect the rear camera cable
properly. Otherwise, the front/main camera will not be able to detect it.
IMPORTANT:
