Rear camera wiring diagram
Hide and run
the rear camera
Rear Camera
This diagram is provided for informational purposes only and is intended as
a general diagram of rear camera wiring. Read all the warnings/precautions
in the Main Camera’s User Manual before installing the rear camera.
DISCLAIMER:
NOTE:
The rear camera is NOT waterproof. Therefore it is only designed to be
mounted inside the vehicle.
