52
NOTE: for more information about the “APP”s, contact your distributor or send an e-mail to:
wecare@roverinstruments.com
NOTE: In OPTIC mode it is possible to analyze the spectrum and measure only vertical/low
band (VL) transponders.
FIBER OPTIC AND REMOTE POWER SUPPLY CABLE CONNECTION
SAT spectrum SPAN “Full EXT”
(from 230 to 2610 MHz).
SAT spectrum SPAN “Full SAT”
(from 930 to 2250 MHz).
RF SPECTRUM FORM OPTIC INGRESS
DC
Optic FIBER
Press the “HOME” key. Touch “OPTIC” and then “SPECT”
or use the encoder.
