13
CHECK-UPS, ADJUSTMENT AND MAINTENANCE
Checking the Oil
Check the engine oil each time prior to operating the motorcycle.
The oil level should be between the upper and lower lines of the oil sight
gauge located on the right cover of the crankcase. The level can also be
checked on the dip stick.
1. Set the motorcycle on level ground, look at the sight gauge for current
oil level. Remove the oil gage plug, wipe the oil gage rod clean and then
insert the gage plug into the crankcase again to check the oil level.
There is no need to completely install the oil gage plug in the crankcase
fill hole.
2. Add lubricating oil up to the upper line when needed, but do not overfill.
3. Finally screw on the oil gage plug tightly.
CAUTION
Never start the engine when there is insufficient lubricating oil. Otherwise, it will cause harm to the
engine.
Lubricating Oil Recommended
The lubricating oil is an important factor affecting
the performance and service life of the engine.
Please refer to the chart for the correct grade of
engine oil based on the environmental conditions
in your area. Do not use any other type of oil other
than what is recommended in the chart. DO NOT
MIX OIL WITH THE GASOLINE.
Lubricating oils of different viscosity shall be
employed in different regions and at different
temperatures.
CHANGING THE OIL,CLEANING OIL FILTER SCREEN
1. of the engine and let the oil drain into an approved collection container.
DO NOT PERFORM THIS PROCEDURE WHILE THE ENGINE IS HOT.
SERIOUS BURNS COULD RESULT FROM CONTACT WITH HOT
OIL.
2. Dispose of the used oil properly. For proper disposal
procedures, contact your local oil recycling center.
3. Clean oil screen and spring with solvent.
4. Clean and replace the oil drain plug making sure it is secure.
Oil in the engine by using the oil gauge plug and/or sight gauge.
