16
ADJUSTING THE THROTTLE CABLE
Make sure the throttle works normally.
Check if the throttle twist grip has the required free operating
movement.
The required free operating movement: 2-6mm (0.078 inches - 0.24
inches) If the grip cannot be moved freely, turn the adjusting nut
located near the throttle twist grip to ensure proper operating
movement.
After adjustment, start the engine and check for the operating
movement again. Repeat the adjustment if necessary until the desired operating movement is obtained.
ADJUSTING THE CARBURETOR
Adjusting procedures of idling speed:
1. Support the vehicle by a stand.
2. Adjust the idling speed by the special designed tool to 1500 ± 150r/min.
CAUTION
Do not try to correct a malfunction carburetor by adjusting the idling speed. If the carburetor is not
functioning properly, it should be repaired by dealer.
Adjust idling speed only when the engine is warmed up or 10 minutes after operation.
