6
MAIN DATA
DESCRIPTION DATA DESCRIPTION DATA
Overall length 1775mm Cylinder bore * Stroke 62*49.5mm
Overall width 770mm Compression ratio 9.0:1
Overall height 1025mm Related power 8.2Kw/8500rpm
Seat height 795mm Related torque 10.0N.m/7000rpm
Wheelbase 1220mm Idle speed
1500±150 rpm
Curb Mass 106Kg Displacement 149ml
Payload 150Kg Spark plug
DR8EA(Torch)
Ground clearance 165mm Front wheel 120/70-12
Max speed 87Km/h Rear wheel 130/70-12
Transmission 5Gea Ignition means C.D.I.
Capacity of fuel tank 6.4L
Brake
Front: Disc
Oil capacity 1.1L Rear: Disc
Lubrication method Pressure, splash Sprocket 428H-106
Clutch Manual / Wet Battery 12N7L-4B
