52
4.24 - Adding the Torqeedo
f)
g)
h)
i)
Remove the forward mainsheet block
and jammer base to reveal a hole.
Locate the two cables extensions supplied with the Torqeedo.
Connect the longer cable extension to
the cable which comes from the top of
the torqeedo handle. Tighten then add
PVC tape around the join.
Pass the cable down through the hole which you revealed in step f.
Ensure the cable is properly seated in the cutout then replace the mainsheet block
and jammer base.
