RSP Compact Series - Tightening Torques; Recommended Equipment; Required Products

M0416-1 version 3.2 7
1.3 Tightening torques
Tightening torques for mounting (screw class 8.8)
Dimension
Torque
M8
24 Nm
M10
47 Nm
M12
82 Nm
M14
131 Nm
M16
200 Nm
Tightening torques for mounting (screw class 12.9)
Dimension
Torque
M8
41 Nm
M10
79 Nm
M12
138 Nm
M14
221 Nm
M16
338 Nm
1.4 Recommended equipment
Equipment recommended for installation and maintenance work
Tools
Applications
Complete set of Allen keys
For all socket head cap screws
Torque wrench
For dismounting and mounting
Torx keys
For dismounting and mounting
Pair of pliers
For dismounting the signal pins
Screwdriver
For removing the air sealings
1.5 Required products
Product
Specification
Note
Grease, 3HXG1000-413
Magnalube-G, Teflon grease
Air sealings.
Grease I0876
Molykote BR2Plus
For locking balls.
Cleaning agent
Industrial alcohol or similar
For cleaning of tool changer and tool
attachment.
Glue
Loctite 480 (or similar)
For gluing the air sealings.
Cloth
Lint free cloth
For cleaning.
NOTE! Chemical resistance protective gloves are recommended when using grease
or cleaning agents such as industrial alcohol. Safety goggles are recommended
when working with cleaning agents such as industrial alcohol. Adequate ventilation
should be provided when chemical substances are used.
