ECT Series User Manual
39
Serial
No.
Change of registers
Probe action
1
60B8 Bit 0 = 1
60B8 Bit 1,4,5
Enable probe 1
Configure the rising edge and falling edge of the enable probe
2
-> 60B9 Bit 0 = 1
The state "probe 1 enabled" is set
3
External probe signal rising edge
4
-> 60B9 Bit 1 = 1
The state "Probe 1 rising edge latch" is set
4a
-> 60BA
The positive position of probe 1 is latched
5
External probe signal falling edge
6
-> 60B9 Bit 2 = 1
The state "Probe 1 falling edge latch" is set
6a
-> 60BB
The negative position of probe 1 is latched
7
-> 60B8 Bit：4
Rising edge latch function: disabled
8
-> 60B9 Bit 0 = 0
The state "Probe 1 rising edge latch" is cleared
8a
-> 60BA
Probe 1 positive position, the latch position remains unchanged
9
-> 60B8 Bit 4 = 1
Rising edge latch function: enable
10
-> 60BA
Probe 1 positive position, the latch position remains unchanged
11
External probe signal rising edge
12
-> 60B9 Bit 1 = 1
The state "Probe 1 rising edge latch" is set
12a
-> 60BA
The positive position of probe 1 is latched
13
-> 60B8 Bit 0 = 0
Probe 1 function: disabled
14
-> 60B9 Bit 0,1,2 = 0
Status bit is cleared
14a
-> 60BA,60BB
No change in the positive/negative latch position of probe 1
Probe timing description
