R86 User Manual
3
2.3 Driver installation requirements
Please install the driver vertically or horizontally, with its front facing forward, top facing
upward to facilitate cooling.
During assembly, avoid drillings and other foreign matters falling inside the driver.
During assembly, please use M3 screw to fix.
When there is vibration source (such as a driller) close to the installation position, please
use a vibrating absorber or a vibration resistant rubber gasket.
When multiple drives are installed in the control cabinet, please pay attention to reserve
enough space for sufficient heat dissipation. If necessary, you can configure cooling fans to
ensure good heat dissipation conditions in the control cabinet.
3. Driver Port and Connection
3.1Port function description
Function
Grade
Definition
Remarks
Power supply input
port
AC
Input AC power
supply
AC 20~80V
DC 24~100V
AC
Input AC power
supply
Motor connection port
B-
connect two terminals
of motor’s phase-B
winding
B+
A-
connect two terminals
of motor’s phase-A
winding
A+
Enable connection
ENA+
Enable control
interface
3.3 ~ 24V level
compatible
ENA-
Pulse connection
PUL+
Pulse input interface
PUL-
DIR+
Direction input
interface
DIR-
