12V Trigger
TheAD-46-100andAD-810-100amplierscantriggerthepowerstateof
downstreamdevicesusingthesupplieddual12Vtriggerports.Theseports
willapply12VDC(12VDCviatip,groundviasleeve).viaa3.5mmmono
mini-jackwhentheamplierispoweredon.Conversely,whentheamplier
isintheoorstandbystate,12VDCwillnolongerbeprovided.
1. Connectthemaleconnectorononeendofa3.5mmmonomini-jack
cabletotheportlabeled“Trigger”,“1”or“2”ontheamplier.Bothports
functionsimultaneouslyandcanbeusedtotriggercontrolofupto2
downstreamdevicesthatsupport12VDCtriggering.
2. Connectthemaleconnectorontheoppositeendofthe3.5mmmono
mini-jackcabletoadownstreamdevicethatiscapableofsupporting
12Vtriggering(12VDCviatip,groundviasleeve).
IR In & Out
TheAD-46-100andAD-810-100amplierscanreceiveIR
inputdirectlyfromanRTIprocessororother3rdparty
IRcontroldevice.Additionally,anyreceivedIRsignals
arerelayedtotheportlabeled“IROut”forusewithan
additionaldownstreamamplierforconcurrentcontrol.
DirectconnectiontoanRTIprocessorrequirestheuse
ofaspecializedcable(notincluded)thathasa3.5mm
stereomini-jackononeend(Connectstotheprocessor)
anda3.5mmmonomini-jackontheoppositeend
(Connectstotheamplier).
PleasenotethattheRTIplatformandproducts
utilize12VIRsignalinglevelsforoperation.
1. Connectthemalemonoconnector(tipandsleeve)ofthe3.5mmmono/stereomini-jackcabletothe
portlabeled“IRIn”ontheamplier.
2. Connectthemalestereoconnector(tip,ring,andsleeve)ontheoppositeendofthe3.5mmmono/
stereomini-jackcabletotheIRoutportonacompatibleRTIprocessororothercompatible3rdparty
IRdevice.
MusicStreamer
RTIControlProcessor
ETHERNET
IN OUT DIGITAL OUT
12V
1 42 3 5 6 7 8
A B A B
A B
A B A B A B A B A B
1 42 3 5 6 7 8
A B A B
A B
A B A B A B A B A B
VOLTAGE / CLOSURE 3A @ 30VDC MAX EA. RELAY / 100mA MAX EA. TRIGGER OUTPUT
12VDC
GND
+
SENSE INPUTS
RELAY / TRIGGER OUTPUTS
INFRARED
1
42
3
5
6
7
INFRARED OUT / SERIAL OUT / POWER SYNC IN
MULTI-PURPOSE I/O PORTS
USB
EXPANSION
12VDC,1A
+
RTI COM
VIDEO OUT
ETHERNET
POWER
