RTK REpos-8010 User Manual

Digitaler Stellungsregler
Digital positioner
Positionneur digital
REpos-8010
19.10.2017 REpos-8010.docx Technische Änderungen vorbehalten / Technical changes reserved / Modifications techniques sous réserve page 55
31.4 Configuration parameter
Configuration parameter
#
Display
Description
Parameter Value
Function
1
Ainp
Analog Input
0-20mA / 4-20mA
0-10V / 2-10V
Setpoint Input type current/ voltage
2
SpRv
Setpoint Inversion
Dir (Direct )
Rev (Reverse)
Changes the direction of the setpoint e.g.
4mA actuator spindle extended or
4mA actuator retraced+ chapter 34
3
Aout
Analog Output Type
0-20mA / 4-20mA
0-10V / 2-10V
Optional
Select feedback signal output type
4
Rinv
Feedback signal Inversion
Dir (Direct )
Rev (Reverse)
Changes the direction of the feedback signal e.g.
4mA actuator spindle extended or
4mA actuator retraced
5
SplM
Split range mode
None, High, Low
+ chapter 35
6
SplT
Split range Threshold
20…80%
Split point
7
Safe
Safety Position
Off
Open
Close
Actuator position in error mode
e.g. Input signal fault.......
8
DBnd
Dead band
0.5…5.0%
neutral Zone between operation commands
open ->close or close->open
9
MnTT
Minimum Travel Timeout
0……1000s
Minimum delay to enter in position error
.+ chapter 38
10
ClTe
Close Tight Enable
En (Enabled)
Dis (Disabled)
Close Tight Function enabling
.+ chapter 37
11
ClTB
Close Tight Band
0.5….5.0%
Close Tight value for open /close limits
12
SpLn
Setpoint Linearization Enable
En (Enabled)
Dis (Disabled)
Setpoint Linearization with max. 21 Interpolation-
points .+ chapter 36
13
SL0
Interpolation point 0 (0%)
0….100%
Parameters are displayed if SpLn is enabled
..
……
……………………………..
………………
……………………………………………………..
………………………………………………
33
SL20
Interpolation point 20 (100%)
0….100%
34
RM.SP
Remote Setpoint Fieldbus
0….100%
If Fieldbus operation is active, the value of the digital
setpoint received is displayed.
35
RSP.H
Remote Setpoint High Limit
0….100%
max. Setpoint value accepted from fieldbus
36
RSP.L
Remote Setpoint Low Limit
0….100%
min Setpoint value accepted from fieldbus
37
PW.GL
Password Global Access
-1999….9999
Password for Config and CMD menu access
38
PW.CF
Password Config Access
-1999….9999
Password for Config menu only
39
FL.cl
Force Local Control
En (Enable)
Dis (Disable)
If Enable remote control from fieldbus is inhibited
40
CBus
Fieldbus selection
None
CAN open
Profibus DP
optional
Fieldbus selection
(Proper optional hardware required)
41
Addr
Node Address
1….127
Fieldbus Node Address -> Parameter displayed
only if fieldbus is active
42
Baud
Baud Rate (Kbit/s)
20,50,100,125,250,
500,1000
Only for CAN open
Profibus baud rate auto selected
43
MB.AD
Modbus Address
1…255
Node Address Modbus
44
MB.BR
Serial Com Baud Rate
4800,9600,19200
38400,57600
Baud rate Modbus Communication

RTK REpos-8010 Specifications

General

Brand	RTK
Model	REpos-8010
Category	Valve Positioners
Language	English
