RTK REpos-8010 User Manual

Digitaler Stellungsregler
Digital positioner
Positionneur digital
REpos-8010
19.10.2017 REpos-8010.docx Technische Änderungen vorbehalten / Technical changes reserved / Modifications techniques sous réserve page 53
31.2 Diagnostic data
Diagnose data
#
Display
Description
Range
Function
1
TrTm
Motor travel time
0….9999
Detected motor travel time during Init procedure
2
S0
Potentiometer value at 0%
0….100%
Potentiometer value at 0% stroke
3
S100
Potentiometer value at 100%
0….100%
Potentiometer value at 100% stroke
4
Hyst
Dead band
0.5….5.0%
Detected dead band during Init procedure
5
WHrs
Working hours
0….999k
Working hours total
6
TStr
Strokes
0….999k
Operating commands total
7
Str1
Strokes within 0..25%
0….999k
Operating commands within 0-25% of real stroke
8
Str2
Strokes within 25..50%
0….999k
Operating commands within 25-50% of real stroke
9
Str3
Strokes within 50...75%
0….999k
Operating commands within 50-75% of real stroke.
10
Str4
Strokes within 75...100%
0….999k
Operating commands within 75-100% of real stroke
11
iErr
Input error
0….999k
Total count input signal out of range
12
SErr
Potentiometer error
0….999k
Total error Potentiometer input
13
CErr
Communication error
0….999k
Total error communication
14
Temp
Temperature
-5°C….80°C
Current „on board“ temperature
15
Tmin
min. temperature
-5°C….80°C
min. „on board“ temperature
16
Tmax
max. temperature
-5°C….80°C
max. on board“ temperature
17
HrT1
Hours in temp. range T1
0….999k
Operating hours in range < 0°C
18
HrT2
Hours in temp. range T2
0….999k
Operating hours in range 0°C….30°C
19
HrT3
Hours in temp. range T3
0….999k
Operating hours in range 30°C….50°C
20
HrT4
Hours in temp. range T4
0….999k
Operating hours in range 50°C….70°C
21
HrT5
Hours in temp. range T5
0….999k
Operating hours in range > 70°C
22
Wlif
Instrument life hours
0….999k
Operating hours total non-resettable
