RTK REpos-8010 User Manual

Digitaler Stellungsregler
Digital positioner
Positionneur digital
REpos-8010
19.10.2017 REpos-8010.docx Technische Änderungen vorbehalten / Technical changes reserved / Modifications techniques sous réserve page 39
Actuator Type REact
Check the resistance in 0% position.
The measured value between the grey and red
wire should be approx. 100[ ±20[
23. Installation REpos
23.1 Required parts
1x mounting bracket
4x screw M4 x10 (TX20)
1x power-board
4x distance bolt (5,5x20mm) self-cutting
1x CPU-board (Display)
4x screw M3 x6 (Philips screw)
optional
signal feedback -module
4x screw 3x6 self-cutting (TX10)
