Digitaler Stellungsregler
Digital positioner
Positionneur digital
19.10.2017 REpos-8010.docx Technische Änderungen vorbehalten / Technical changes reserved / Modifications techniques sous réserve page 35
20. General Information
20.1 Warning!
Before beginning the installation or operation of electrical equipment, please read the following print
"Warnings of hazards..."
” All work on electrical systems or production equipment must be carried out by authorized personnel.
Electrical installation (cables) must be carried out according to the regulations applicable in the
respective countries (Germany VDE 100).
Measurement and signal cable must be kept separate from power cables to avoid EMC effects.
If a riskless operation is no longer possible, the equipment must be taken out of service and made safe
against accidental operation.
l The electronics in the positioner contains components that are susceptible to electric static.
Electric static discharges must be avoided using suitable measures.
21. Technical details
21.1 Electromagnetic compatibility (EMC)
Regarding EMC the positioner complies with the following regulations and directives:
Directive 2014/35/EU and EN61010-1:2011-07 for electrical equipment
Directive 2004/108/EEC for electromagnetic compatibility.
Regulations for HF Emission: EN61000-6-4:2007 for industrial environment
Regulations for HF Immunity to interference: EN61000-6-2:2005 for industrial equipment
21.2 Electrical details
128*64 dot graphic display
current 0(4)-20mA/ R
i
ca. 10[ /voltage 0(2)-10V R
i
ca. 100k[
control output AC version
solid state relays (SSR) max 250V / 50/60Hz 2.5A
control output DC version
high side transistor 24 V dc 100mA max
conductive plastic 1k[ or angle sensor (U
v
5V)
current 0(4)-20mA/ R
L
ca. 500[ /voltage 0(2)-10V galvanic isolated
115/230V 50/60Hz or 24V 50/60Hz or 24V dc
plug connector supply AWG 24-12 / signal AWG 26-16
