RTS Zeus - Figure 17. UIO-256 Interconnect Cable; Figure 18. a Single-Channel TW Belt Pack Cable (for BP-318 Belt Pack); Figure 19. a Power Distribution Cable for TW Belt Packs; Figure 20. an Audio Termination Plug for Use with the TW5 W Splitter

24 Getting Started, Zeus™ DSP Intercom Matrix
TO UIO-256
J2
6
2
1
2
1
TO ZEUS J26
DE-9P (MALE) DE-9P (MALE)
RS485 DATA
-
+
-
+
Figure 17. UIO-256 interconnect cable.
3-PIN XLR
(Female)
3-PIN XLR
(Male)
2
1
3
2
1
3
GG
To SSA-324
“Y” Cable
To BP-318
Belt Pack
Shields optional. Connect to
Ground (G)Terminal.
Figure 18. A single-channel “TW” belt pack cable
(for BP-318 belt pack).
3-PIN XLR
(Female)
3-PIN XLR
(Male)
3
2
1
3
2
1
No Connection
G
G
No Connection
Figure 19. A power distribution cable for “TW”
belt packs.
1
3
22 µF
50 Vdc
200 ohm
+
WIRES MUST NOT TOUCH!
3-Pin XLR
Female
Connector
Figure 20. An audio termination plug for use with
the TW5W splitter.
TO SSA-324 TB1
CONNECTOR
SYSTEM A OR (B)
1
2
6
4
5
9
7
8
AUDIO TO ZEUS
AUDIO FROM ZEUS
+
-
+
-
3
3 (7)
4 (8)
2 (6)
1 (5)
DE-9S (FEMALE)
TO ZEUS J1-J24
+
-
+
-
Note: Shields optional. If
used, do not connect at
SSA-324 end!
Figure 21. A cable to connect a 4-wire channel
from an SSA-324 to a Zeus channel.
3-PIN XLR
(MALE)
2
1
3
DE-9S (FEMALE)
TO ZEUS J1-J24
1
2
6
4
5
9
7
8
3
TO 4020M
IFB BELT PACK
AUDIO FROM ZEUS
+
-
+
-
Figure 22. 4020M interconnect cable.
