Horizontal Double Suction Centrifugal Pump – API 610 Process Pump
54 V1.032818
24. Remove the radial oil ring.
25. Remove the hex bolts that secure the radial bearing housing to the case.
26. Remove the radial bearing housing.
RADIAL (COUPLING SIDE) BEARING
27. Unbend the tab of the radial bearing lock washer from the groove of the radial bearing lock
nut.
28. Remove the radial bearing lock nut.
29. Remove the radial bearing lock washer.
30. Remove the radial bearing sleeve.
31. Remove the radial bearing.
32. Remove the radial bearing spacer.
33. Remove the internal radial bearing housing cover.
AXIAL (NON-COUPLING SIDE) MECHANICAL SEAL
34. Remove the hex bolts that secure the axial mechanical seal to the case.
35. Remove the axial mechanical seal.
36. Remove the axial throat bushing.
RADIAL (COUPLING SIDE) MECHANICAL SEAL
37. Remove the hex bolts that secure the radial mechanical seal to the case.
38. Remove radial mechanical seal.
39. Remove the radial throat bushing.
CASING COVER
40. Remove the hex nuts that secure the casing cover to the case.
41. Remove the studs that join the casing cover to the case.
42. Remove the casing cover.
43. Remove the socket set screws that fix the axial case wear ring to the casing cover.
44. Remove the axial case wear ring.
