J Line Pump
Horizontal Double Suction Centrifugal Pump ā API 610 Process Pump
56 V1.032818
8. Remove the external axial bearing housing cover.
9. Remove the hex bolts that secure the internal axial bearing housing cover to the axial bearing
housing.
10. Remove the hex bolts that secure the axial bearing housing to the axial casing cover.
11. Remove the axial bearing housing.
AXIAL (NON-COUPLING SIDE) BEARINGS
12. Unbend the tab of the axial lock washer from the groove of the axial lock nut.
13. Remove the axial bearing lock nut.
14. Remove the axial lock washer.
15. Remove the axial oil ring.
16. Remove the axial bearing sleeve.
17. Remove the second axial bearing.
18. Remove the first axial bearing.
19. Remove the axial bearing spacer.
20. Remove the internal axial bearing housing cover.
AXIAL (NON-COUPLING SIDE) MECHANICAL SEAL
21. Remove the hex bolts that secure the axial mechanical seal to the axial casing cover.
22. Remove the axial mechanical seal.
RADIAL (COUPLING SIDE) BEARING HOUSING
23. Remove the hex bolts that secure the external radial bearing housing cover to the radial
bearing housing.
24. Remove the external radial bearing housing cover.
25. Remove the hex bolts that secure the internal radial bearing housing cover to the radial
casing cover.
26. Remove the hex bolts that secure the radial bearing housing to the radial casing cover.
27. Remove the radial bearing housing.
