J Line Pump
Horizontal Double Suction Centrifugal Pump ā API 610 Process Pump
82 V1.032818
44. Manually place and tighten the hex bolts to secure the external radial bearing housing cover
to the radial bearing housing.
Figure 8.43. Placing and tightening the hex bolts to secure the external radial bearing housing cover to the radial
bearing housing.
NON-COUPLING SIDE (AXIAL) BEARINGS
45. Place the corresponding gasket on the internal axial bearing cover.
Figure 8.44. Placing the corresponding gasket on the internal axial bearing cover.
