7. Before tightening all bolts and nuts with a spanner, adjust the length of the coupling guard to close the
distance between the coupling guard and the motor to approximately ⅛ inch (3.175 mm).
8. Tighten all the bolts and nuts with a spanner to rigid the assembly.
Figure 8.50 Coupling guard assembly.
