Ruide Disteo 23 - Stake out of any Point

9
Step 4: Press F1 to measure. Indicate the
poleman to move the prism according to the
indications on the screen, until all the values on
the screen are 0.
H Diff
the angle difference between
the HA of Point A to staking out
point and the HA of current
target
+↑/-↓
offset of perpendicular to the axis
+L/-R
offset along the axis
SwPt
Return to input offset to start a
new point.
6.2 Stake Out of Any Point
This is the stake out provided that the theodolite
is set at any point outside the axis.
Select F2.
Step 1: Measure the distance to Point A and B,
then press F4 to next step.
