11. SPECIFICATION
TELESCOPE
Erect
Magnification
26.5X
Aperture (telescope)
40mm
Aperture (distance)
45mm
Resolution
3”
Field of View
1°30”
Min. Focusing
1.5m
Length
155mm
LASER
Wave Length
635+20nm
Class
II
Diameter of Laser Dot
≤5mm/100m
Accuracy
≤10”
ANGLE
Type
Absolute Encoding
Diameter of Disk
79mm
Detecting Method
Horizontal: dual; Vertical: dual
DISTANCE
Reflecting Target
Single Prism
Range
300m
Accuracy
+(3mm+2ppm*D)
Time
Continuous: 0.35s; Fine: 1.5s
Atmospheric Correction
Manual input, auto correct.
Prism Constant Corr.
Manual input, auto correct.
LEVEL
Plate Vial
30”/2mm
Circular Vial
8’/2mm
COMPENSATOR
Type
Single Axis
Range
+3’
Resolution
3”
LASER PLUMMET
Type
Class II visible red laser
Wave of Length
635+20nm
Accuracy
1.5mm (when HT 1.5m)
Diameter
2.5mm (when HT 1.5m)
DISPLAY
Type
160*96 Dot Matrix
Size
2.7 inch
POWER
