1.6.2 Advanced Parameter Setting

On the main interface press the key to enter the Data Setting Interface. In the

Data Setting Interface press key or key to step up or down through the menu

options to select (Voltage) or (Current Limit),and then set the output

Voltage and output Current Limit in the same way as used in the main interface.

1.6.2.1 Protection Values Setting

Switch to (Over-Voltage Protection), (Over-Current Protection) or

(Over-Power Protection) limits. We can set the value of Over-Voltage protection

value, Over-Current protection value and Over-Power protection value. When any of the

protection value limits are reached ,the output will be automatically disabled, and there will

be displayed on the interface; When the temperature of Power board exceeds

80 ℃ ,the output will be automatically disabled, and there will be displayed on the

interface. Press the rotary control to place the cursor at the required character, and turn the

rotary control to set the value. Press key to exit.

1.6.2.2 Screen Brightness Setting

Switch to , press the rotary control to select the character you want to change.

Turn the rotary control to adjust the brightness from 0 to 5 where 0 is the darkest and 5 is

the brightest. Press key to exit. It’s up to you to set the brightness you like.

1.6.2.3 Data Settings and Saving In Specified Data Group

Switch to ,press the rotary control to select Data Group Number, press key

and then press key or key to step up or down through the menu options, press the

rotary control to set the value you need. Press key for over 2 seconds and the data will

be saved in this Data Group.in the meanwhile the Data Group Number is shown on the right

hand side of the screen. Press key to exit.

1.6.2.4 M-PRE ON / OFF Setting

Switch to , press and turn the rotary control to Data Group Number you want

to check, then all the data will be shown to you, press rotary control again so that you can

adjust M-PRE option. Turn the rotary control to select either ON or OFF. When ON is selected

it signifies that when the Data Group is recalled the state of the unit main output will remain

the same as it was prior to the Data Group recall. When OFF is selected it signifies that when

the Data Group is recalled the state of the unit main output will be set to OFF regardless of
