RG-ES206GS-P Series Switches Hardware Installation and Reference Guide Product Overview
3
EEE
Not supported
PoE
PoE standards: IEEE802.3af and 802.3at.
Ports 1-4 are PoE/PoE+ ports, each supporting a maximum PoE+ output of 30 W.
Ports 5 and 6 do not support PoE standard.
Overall max. PoE/PoE+ power output: 54 W
PoE Power Cable
Pairs
Mode A (1-2, 3-6 pairs)
Max. Power
Consumption
Power consumption (No PoE load) < 6W
Power consumption (PoE full load) < 60W
Port Status LED
Toggle Switch
LED switch toggled to left (Mode 1): the port LED status indicates the status of
traffic transmission. Solid green means that the port is link up, while blinking green
means that the port is transmitting and receiving data.
LED switch toggled to right (Mode 2): The port LED status indicates the PoE
status. Solid green means that the port is supplying power, while blinking green
means that the port is in power overload state.
Reset Button
Press the button for less than 2 seconds and release, the switch restarts.
Press the button for more than 5 seconds and release after the system LED starts
blinking, the switch restores to factory defaults and restarts.
Operating
Temperature
0ºC to 40ºC
Storage
Temperature
–40°C to +70°C
Operating
Humidity
10% to 90% RH (non-condensing)
Storage Humidity
5% to 95% RH (non-condensing)
Fan
Fanless design
Temperature Alarm
Not supported
DDM
Not supported
Safety Standard
CE Certification
Max. Ground
Leakage Current
≤ 1.5 mA
Dimensions (W x D
x H)
149 mm (5.87 in.) x 79 mm (3.11 in.) x 26 mm (1.02 in.)
Weight
1.1 kg (12.79 lbs, package included)
