Ruijie Reyee RG-NBS Series User Manual

Web-based Configuration Guide L2 Multicast
81
Parameter
Description
Default Value
Multicast VLAN
VLAN of a multicast source
1
Start IP Address
Learned or configured start multicast IP address of an MVR
multicast group.
NA
End IP Address
Learned or configured end multicast IP address of an MVR
multicast group.
NA
5.4.3 Configuring the MVR Ports
Choose Local Device > L2 Multicast > MVR.
Batch configure: Click Batch Edit, select the port role, the port to be set, and whether to enable the Fast Leave
function on the port, and click OK.
Configure one port: Click the drop-down list box to select the MVR role type of the port. Click the switch in the
Fast Leave column to set whether the port enables the fast leave function.
