Web-based Configuration Guide L2 Multicast
82
Table 5-4 Description of MVR Configuration Parameters of Ports
NONE: Indicates that the MVR function is disabled.
SOURCE: Indicates the source port that receives multicast
data streams.
RECEIVER: Indicates the receiver port connected to a client.
Configures the fast leave function for a port. After the function
is enabled, if the port receives the leave packet, it is directly
deleted from the multicast group.
Note
● If a source port or a receiver port is configured, the source port must belong to the MVR VLAN and the
receiver port must not belong to the MVR VLAN.
● The fast leave function takes effect only on the receiver port.
5.5 Configuring Multicast Group
Choose Local Device > L2 Multicast > Multicast Group.
A multicast group consists of the destination ports, to which multicast packets are to be sent. Multicast packets
are sent to all ports in the multicast group.
You can view the Multicast List on the current page. The search box in the upper-right corner supports
searching for multicast group entries based on VLAN IDs or multicast addresses.
Click Add to create a multicast group.
