Hardware Installation and Reference Guide Product Overview
10
Safety Regulation
Compliance
0°C to 45°C (32°F to 113°F)
–40°C to 70°C (–40°F to 158°F)
10% to 90% RH (non-condensing)
Net weight: 10 kg (20.05 lbs., with 4 fan modules and 2 power modules)
442 mm x 387 mm x 44 mm (17.40 in. x 15.24 in. x 1.73 in.), 1U
Caution
The RG-S6150-24VS8CQ-X is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Note
The 25G/100G Ethernet port of the RG-S6150-48VS8CQ-X switch does not support direct attach copper
(DAC).
The 24VS port license supports 25G port and does not support FEC-RS.
Product Appearance
The hardware of the S6150-24VS8CQ-X includes the chassis, the power supply system and the heat
dissipation system.
The power supply system: Provides two power supply slots, which support 1+1 power supply redundancy.
You are advised to configure power supply redundancy.
The heat dissipation system: Provides four fan module slots, which support 3+1 fan redundancy. You are
advised to configure all fans redundancy.
Figure 1-6 Appearance of the RG-S6150-24VS8CQ-X
