Hardware Installation and Reference Guide Overview
5
1.5 Specifications
Table 1-5 Specifications
Model
RG-WALL 1600-Z3200-S
Storage
DDR4 SDRAM: 4 GB
Boot ROM: 8 MB
eMMC: 8 GB
SATA hard disk: 1 TB
Port
The firewall supports eight electrical ports and two optical ports.
Electrical port: works at a rate of 10 Mbps, 100 Mbps, or 1000 Mbps in auto-
negotiation mode and automatically identifies network cables and crossover
cables.
Gigabit optical port: supports 1000BASE-SX/LX/ZX mini GBIC and GE-SFP-
LX20/LH40-BIDI optical modules.
10 Gigabit optical port: supports XG-SFP-SR-MM850, XG-SFP-LR-SM1310, and
XG-SFP-ER-SM1550 optical modules, as well as BIDI optical modules.
MGMT port
Used as GE 0/0 port. It works at a rate of 10 Mbps, 100 Mbps, or 1000 Mbps in auto-
negotiation mode and automatically identifies network cables and crossover cables.
Console port: 1
USB port: two USB 2.0 ports
Bypass
Not supported
Expansion Slot for
Hard Disk
(Optional) One 1 TB hard disk can be configured.
Expansion Card
Not supported
Hot Swapping
Hard disk: not supported
Port Standards
Ethernet port: 10Base-T/100Base-TX/1000Base-TX, 1000BASE-SX/LX/ZX, and
10GBASE-SR/LR/ZR
Console port: RS-232
Dimensions
(H x W x D)
43.6 mm x 440 mm × 200 mm (1.72 in. x 17.32 in. x 7.87 in.; without rubber pads)
Power Supply
100–240 V AC, 50–60 Hz; 0.65 A
Max. Power
Consumption
Less than 25 W
Temperature
0°C to 45°C (32°F to 113°F)
Operating Humidity
10% to 90% RH (non-condensing)
